How To Upgrade IOS On Cisco 3560 Switches?

Jul 05 , 2022 5531

Do you want to upgrade Cisco 3560 switch IOS? It is very easy, you only need to do these 4 steps. Below are the details about how to do it.

Cisco 3560 series switches.jpg

Cisco 3560 Switches

1. Tools Needed

CISCO 3560 switch, PC with Super Terminal installed, TFTP or FTP server, c3560-advipservicesk9-mz.122-25.SEE2.bin

2. Backup IOS

Use the dir, cd, pwd and other commands to see the directory structure in the flash before performing the backup. The bin file and html folder of this switch IOS are in the c3560-ipbase-mz.122-25.SEB4 directory in the flash.

2.1 Back up the original IOS to the TFTP server with IP 192.168.1.100.

switch#copy flash:/c3560-ipbase-mz.122-25.SEB4/c3560-ipbase-mz.122-25.SEB4.bin
tftp://192.168.1.100/c3560-ipbase-mz.122-25.SEB4.bin

2.2 Back up the original IOS as a tar file to the TFTP server with IP address 192.168.1.100.

switch#archive tar /create tftp://192.168.1.100/c3560-ipbase-mz.122-25.SEB4.tar
flash:/c3560-ipbase-mz.122-25.SEB4

3. Upload new IOS

Copy the new IOS to the root directory of the flash

switch#copy tftp://192.168.1.100/c3560-advipservicesk9-mz.122-25.SEE2.bin
flash:/c3560-advipservicesk9-mz.122-25.SEE2.bin

(Note: If you are using CISCO-specific TFTP software, the TFTP software will be shut down immediately after running this command. In this case, you need to manually start the TFTP software again.)

4. Change the start up settings

4.1 Let the switch start with the new IOS

Switch(config)#boot system flash:/c3560-advipservicesk9-mz.122-25.SEE2.bin

4.2 Set up an alternate IOS boot

switch(config)#boot boothlpr flash:/c3560-ipbase-mz.122-25.SEB4/c3560-ipbase-mz.122-25.SEB4.bin
switch#write
switch#reload

After rebooting, the switch will use the new IOS.Common questions: Switch IOS loading order issues.Switch IOS boot sequence: start help ios (boot boothlpr) --- help ios (boot helper) --- system ios (boot system)

Have any question about Cisco switches, please feel free to contact us. Also provide second hand used and brand new Cisco 3560 series switches.
