C9200L-48PXG-2Y-A | |
Product list | |
Product code | C9200L-48PXG-2Y-A |
Fans | Fixed redundant |
Software | Network Advantage |
Product parameters | |
Stacking bandwidth | 80 Gbps |
Network Ports | 48 |
Expansion Slots | 4 |
Expansion Slot Type | SFP |
Port Details | 48 x Gigabit Ethernet Network 4 x Gigabit Ethernet Uplink |
Ethernet Technology | Gigabit Ethernet |
Network Technology | 10/100/1000Base-T 1000Base-X |
Layer Supported | 2 |
Introduction | C9200L-48PXG-2Y-A is the C9200L 48-port (8xmGig, 40x1G), 2x25G PoE+, Network Advantage. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified. |
DRAM | 2 GB |
Flash | 4 GB |
Physical specifications | |
Width | 17.5 in |
Height | 1.7 in |
Depth | 13.8 in |
Weight | 9.59 lb |
Environmental Parameters | |
Min Temperature | 23 °F |
Max Temperature | 131 °F |
Humidity Operating | 5 - 95% (non-condensing) |
