Dimensions & Weight |
Width | 17.5 in |
Depth | 19.1 in |
Height | 1.7 in |
Weight | 16.71 lbs |
Interface Provided |
Qty | 8 |
Type | Management (mini-USB) |
Connector Type | Type B |
Comments | Management |
PoE Power | 60 W |
Miscellaneous |
Rack Mounting Kit | Included |
Compliant Standards | BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A, GOST, ICES-003 Class A, IEC 60950-1 Second Edition, ISO 7779, KCC, KN22 Class A, KN24, NOM, RoHS, UL 60950-1 Second Edition, VCCI Class A |
Authentication Method | Kerberos, RADIUS, Secure Shell (SSH), TACACS+ |
MTBF | 233,780 hours |
Height (Rack Units) | 1 |
Color Category | Black |
Networking |
Type | Switch |
Connectivity Technology | Wired |
Remote Management Protocol | CLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet |
Compliant Standards | IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Status Indicators | Active, PoE, Port duplex mode, Port transmission speed, Status, System |
Ports Qty | 24 |
Features | Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Cisco StackWise Technology, Class of Service (CoS), DHCP snooping, DHCP support, DiffServ Code Point (DSCP) support, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient Ethernet, Flexible NetFlow (FNF), Full duplex capability, Hot Standby Router Protocol (HSRP) support, IGMP snooping, IPv6 support, Layer 2 switching, Link Aggregation Control Protocol (LACP), LLDP support, MAC Address Notification, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Spanning Tree Protocol (STP) support, Strict Priority Queuing (SPQ), Syslog support, Trivial File Transfer Protocol (TFTP) support, Trunking, Uni-Directional Link Detection (UDLD), Unicast Reverse Path Forwarding (URPF), Virtual Route Forwarding-Lite (VRF-Lite), VLAN support |
Routing Protocol | BGP-4, EIGRP for IPv6, IS-IS, OSPFv3, PIM-DM, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, Static IP routing |
MAC Address Table Size | 32000 entries |
Stackable | Stackable |
Subcategory | Network hubs and switches |
Power Over Ethernet (PoE) | UPOE |
Advanced Switching | Layer 3 |
Manageable | Yes |
Form Factor | Desktop, Rack-mountable |
Jumbo Frame Support | 9198 bytes |
Subtype | Gigabit Ethernet |
PoE Budget | 820 W |
Performance |
Type | Switching capacity |
Value | 272 Gbps |
Ports |
Qty | 16 |
Type | 10/100/1000 (UPOE) |
Ports (2nd) |
Qty | 8 |
Type | 100/1000/2.5G/5G/10G (UPOE) |
Ports (3rd) |
Qty | 4 |
Type | 10 Gigabit SFP+ (uplink) |
Power Device |
Frequency Required | 50/60 Hz |
Power Provided | 1100 Watt |
Installed Qty | 1 |
Max Supported Qty | 2 |
Nominal Voltage | AC 120/230 V |
Power Redundancy | Optional |
Power Redundancy Scheme | 1+1 (with optional power supply) |
Type | Internal power supply |
Hot-Plug | Hot-plug |
RAM |
Installed Size | 4 GB |
