AIR-PWRINJ-FIB|LinkNewNet

AIR-CAP3602E-E-K9 Cisco 3600e Series Access Points: Dual Band

Model: AIR-CAP3602E-E-K9

Detail: Cisco AIR-CAP3602E-E-K9 802.11n CAP w/CleanAir; 4x4:3SS; Mod; Ext Ant; E Reg Domain

Condition: USED

List Price: $927 Price: $556

Price is not finalPlease contact if any inquiry.

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

AIR-CAP3602E-E-K9 Specifications
Software	Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers: ● 7.2 or later for the Cisco Aironet 3600 Series Access Point ● 7.4 or later for support of the Wireless Security Module for the 3600 Series Access Point ● 7.5 or later for support of the 802.11ac Wave 1 Module for the 3600 Series Access Point Cisco IOS XE Software Release: ● 3.2.0SE or later for the Cisco Aironet 3600 Series Access Point ● 3.3.0SE or later for the Cisco 802.11ac Wave 1 Module for the 3600 Series Access Point ● Wireless Security Module for the 3600 Series Access Point support
Supported Wireless LAN Controllers	AireOS Wireless Controllers ● Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst ® 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco Flex ® 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco Virtual Wireless Controller Cisco IOS Wireless Controllers ● Cisco 5760 Wireless LAN Controller, Cisco Catalyst 3850 Series Switches, Cisco Catalyst 3650 Series Switches
Integrated Antenna	● 2.4 GHz, Gain 2 dBi, internal omni, horizontal beamwidth 360° ● 5 GHz, Gain 4 dBi, internal omni, horizontal beamwidth 360°
External Antenna (Sold Separately)	● Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz) ● Cisco offers the industry's broadest selection of 802.11n antennas delivering optimal coverage for a variety of deployment scenarios
Interfaces	● 10/100/1000BASE-T autosensing (RJ-45) ● Management console port (RJ-45)
Indicators	● Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
Dimensions (W x L x H)	● Access point (without mounting bracket): 8.7 x 8.7 x 2.11 in. (22.1 x 22.1 x 5.4 cm)
Weight	● 2.5 lbs (1.13 kg)
Environmental	Cisco Aironet 3600i ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test -25˚C, 15,000 ft. ● Operating temperature: 32 to 104°F (0 to 40°C) ● Operating humidity: 10 to 90% percent (noncondensing) ● Operating Altitude Test -40˚C, 9843 ft. Cisco Aironet 3600e ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test - 25˚C, 15,000 ft. ● Operating temperature: -4 to 131°F (-20 to 55°C) ● Operating humidity: 10 to 90 percent (noncondensing) ● Operating Altitude Test -40˚C, 9843 ft.
System Memory	● 256-MB DRAM ● 32-MB flash
Input Power Requirements	● AP3600: 44 to 57 VDC ● Power Supply and Power Injector: 100 to 240 VAC; 50 to 60 Hz
Power draw	* This is the power required at the PSE, which is a switch or injector.
Power draw	Description	AP Functionality	PoE Budget (Watts)	802.3af	E-PoE	802.3at PoE+ PWRINJ4
PoE+ 802.3at	3600 - No external module installed	4x4:3 on 2.4/5 GHz	15.4	ü	ü	ü
PoE+ 802.3at	3600 - 2.4GHz radio disabled + Wireless Security Module	4x4:3 on 5 GHz + WSM	15.4	ü	n/a	n/a
	3600 - 2.4GHz radio disabled + 802.11ac Module	4x4:3 on 5 GHz only + 11ac	15.4	ü	n/a	n/a
PoE 802.3af	3600 + Wireless Security Module	4x4:3 on 2.4/5 GHz + WSM	18.4	×	ü	ü
PoE 802.3af	3600 + 802.11ac Module	4x4:3 on 2.4/5 GHz + 11ac	19.6	×	ü	ü
	3600 + Universal Small Cell Module (USC5310)	4x4:3 on 2.4/5 GHz + USC5310	22	×	×	ü
Warranty	Limited Lifetime Hardware Warranty

Q&A

What common troubleshooting steps are available for the Cisco AIR-CAP3602E-E-K9?

Common steps include checking the connections, verifying the configurations, and rebooting the access point.

What accessories are available for the Cisco AIR-CAP3602E-E-K9?

Accessories include external antennas, mounting kits, and power injectors.

How does the Cisco AIR-CAP3602E-E-K9 compare to other Cisco access points?

Compared to the Cisco 2600 Series, the 3600 Series offers enhanced performance with CleanAir technology and additional spatial streams.

How do I use the CleanAir technology in the Cisco AIR-CAP3602E-E-K9?

CleanAir technology automatically detects and mitigates RF interference, providing a clearer, more reliable wireless signal.

Is the AIR-CAP3602E-E-K9 cost-effective?

Yes, the AIR-CAP3602E-E-K9 offers robust performance with 802.11n and CleanAir technology, providing excellent value for high-density environments.

What are the key features of this product?

Key features include 802.11n support, CleanAir technology, 4x4:3 MIMO, modular design, and support for external antennas in the E Regulatory Domain.

What are the primary application scenarios?

Ideal for high-density wireless environments such as offices, schools, hospitals, and large venues that require reliable Wi-Fi coverage and performance.

How do I install the AIR-CAP3602E-E-K9?

Follow the installation guide included in the package. Mount the device, connect to the network, and configure via the related Cisco controller software.

Does this product need regular upgrades?

Yes, to ensure optimal performance and security, keep the firmware updated, typically through Cisco's provided updates and patches.

Are there alternative products?

Alternatives include the Cisco 3702E and 3802E series access points, which offer similar or enhanced capabilities depending on your specific needs.

What accessories are available?

Accessories include a variety of external antennas, mounting brackets, and power adapters compatible with the AIR-CAP3602E-E-K9.

How does it compare to similar products?

The AIR-CAP3602E-E-K9 offers enhanced RF management with CleanAir and robust performance with 4x4:3 MIMO compared to many other 802.11n access points.

What common issues may arise?

Common issues include connectivity drops and interference, often resolved through firmware updates and proper placement of external antennas.

What regulatory domain does this cover?

The AIR-CAP3602E-E-K9 covers the E Regulatory Domain, which typically includes countries in the European region, ensuring compliance with local regulations.

How cost-effective is the Cisco AIR-CAP3602E-E-K9?

The Cisco AIR-CAP3602E-E-K9 offers high performance and CleanAir technology, making it a cost-effective solution for robust wireless connectivity.

What are the features of the Cisco AIR-CAP3602E-E-K9?

The Cisco AIR-CAP3602E-E-K9 features 802.11n, CleanAir technology, 4x4:3SS, and modular design with external antenna support.

What are the application scenarios for the Cisco AIR-CAP3602E-E-K9?

This access point is ideal for high-density wireless environments such as large enterprises, universities, and public venues.

How do I install the Cisco AIR-CAP3602E-E-K9?

The installation involves mounting the access point, connecting to the network, and configuring it via the Cisco Wireless Controller.

Does the Cisco AIR-CAP3602E-E-K9 need software upgrades?

Yes, periodically updating the firmware is recommended to ensure optimal performance and security.

Are there alternative products to the Cisco AIR-CAP3602E-E-K9?

Yes, alternatives include the Cisco 3700 Series access points, which provide similar functionalities with higher performance.
