C9400-LC-48P-B1 - Cisco Catalyst 9400 Series Line Card

Product Description

Cisco Catalyst 9400 Series 1xC9400-LC-48P for Bundle Select

Number of ports

48

Port speed

10/100/1000

Port type

RJ-45 POE+ IEEE 802.3at, IEEE 802.3af,Cisco pre-standard

Cisco Catalyst 9400 Series switch min/max ports

Chassis C9404R: 48/96

Chassis C9407R:48/240

Chassis C9410R:48/384

Bandwidth per slot

C9400 Supervisor Engine-1 (C9400-SUP1)

Chassis C9404R:80 Gbps

Chassis C9407R:80 Gbps

Chassis C9410R:80 Gbps

C9400 Supervisor Engine-1XL (C9400-

SUP-1XL)

Chassis C9404R:240 Gbps

Chassis C9407R:120 Gbps

Chassis C9410R:80 Gbps

C9400 Supervisor Engine-1XL-Y (C9400-

SUP-1XL-Y)

Chassis C9404R:240 Gbps

Chassis C9407R:120 Gbps

Chassis C9410R:80 Gbps

Max rated power (W)

65

Rated MTBF (hours)

980,440

Standards

Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3bt, IEEE 802.3at, IEEE 802.3af, IEEE 802.3az,

IEEE 802.3bz, IEEE 802.3an, IEEE 802.3an

EtherChannel technology

● Gigabit EtherChannel: All 1000 Mbps ports

● 10 Gigabit EtherChannel: All 10Gbps ports

●IEEE 802.3ad (Link Aggregation Control Protocol)

● Port Aggregation Protocol (PaGP): Yes

● Number of ports per tuple: 16 with LACP and 8 with PaGP

● EtherChannel and IEEE 802.3ad technology across line cards: Yes

Physical dimensions

● Occupies one slot in Cisco Catalyst 9400 Series switches

● Dimensions (H x W x D): 1.6 x 14.92 x 14.57 in. (4.06 x 37.90 x 37.00 cm)

Environmental conditions

● Operating temperature:

● Normal Operating* Temperature and Altitudes:

◦ 23° to 113°F (-5 to +45°C), up to 6,000 feet (1800 m)

◦ 23° to 104°F (-5 to +40°C), up to 10,000 feet (3000 m)

◦*Minimum ambient temperature for cold startup is 0°C

● Short-Term** Exceptional Conditions:

◦ 23° to 131°F (-5 to +55°C), up to 6,000 feet (1800 m)

◦ 23° to 122°F (-5 to +50°C), up to 10,000 feet (3000 m)

◦ **Not more than following in one-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences

● Storage temperature: -40° to 158° F (-40° to 70°C)

● Relative humidity: 10 to 95%, noncondensing

● Operating altitude: -60 to 3000m

Safety conditions

Fiber optic lasers: Class 1 laser products

Safety certifications

● UL 60950-1

● CAN/CSA-C222.2 No. 60950-1

● EN 60950-1

● IEC 60950-1

● AS/NZS 60950.1

● IEEE 802.3

Safety certifications

● UL 60950-1

● CAN/CSA-C222.2 No. 60950-1

● EN 60950-1

● IEC 60950-1

● AS/NZS 60950.1

● IEEE 802.3
