| CISCO887W-GN-A-K9 Specification | |
| Product Number | CISCO887W-GN-A-K9 |
| Description | Cisco 887 ADSL2/2+ Annex A Router with 802.11n FCC Compliant |
| Default and maximum flash memory | 128 MB |
| WAN | ● Fast Ethernet ● Multimode VDSL2 and ADSl2/2+ over ISDN with ISDN backup ● Multimode VDSL2 and ADSl2/2+ over basic telephone service ● ADSL2/2+ over ISDN with ISDN backup ● ADSL2/2+ over basic telephone service with ISDN backup ● VDSL2 over basic telephone service with ISDN backup ● Multimode G.SHDSL (2- and 4-wire support) with ISDN backup ● Fast Ethernet and 3G WAN for Code Division Multiple Access (CDMA) and high-speed downlink packet access (HSDPA) |
| LAN switch | Managed 4-port 10/100BASE-T with autosensing Media Device In/Media Device Cross-Over (MDI/MDX) for auto crossover |
| Standard 802.11g/n access point based on IEEE 802.11n draft 2.0 standard | Optional on all models |
| Console or auxiliary port | RJ-45 |
| One USB 1.1 port for advanced security features such as security tokens or USB flash memory | ● One USB 1.1 port on Cisco 880 Series Routers ● USB devices supported: ● USB eTokens ● USB flash memory |
| External power supply | Universal 100 to 240 VAC input; 60W, 12 VDC output |
| Physical dimensions and weight | Product dimensions, wireless models (H x W x D): ● 1.9 x 12.8 x 10.4 in. (48 x 325 x 264 mm) (includes rubber feet) ● 1.75 x 12.8 x 10.4 in. (44 x 325 x 264 mm) (without rubber feet; excludes antennas) ● Weight: 5.5 lb (2.5 kg) maximum |
| Power | Product power specifications: ● AC input voltage: 100 to 240 VAC ● Frequency: 50 to 60 Hz ● Maximum output power: 60W ● Output voltages: 12 VDC Optional internal PoE with external adapter: ● Maximum output power: 80W ● External output voltage: 48 VDC |
