Juniper EX-SFP-10GE-LRM Specifications | |
Product Type | 10 Gigabit SFP+ LRM Optic |
Brand | Juniper |
Compatibility | Designed for use with Juniper Networks devices |
Data Transfer Rate | 10 Gbps |
Form Factor | Small Form Factor Pluggable (SFP+) |
Connector Type | LC |
Cabling Type | Multi-mode Fiber (MMF) |
Max Transmission Distance | 220m on standard Fiber Distributed Data Interface (FDDI) grade MMF |
Wavelength | 1310nm |
Power Consumption | Typical 1.2W, Max 1.5W |
Operating Temperature | 0 to 70��C (32 to 158��F) |
Digital Optical Monitoring (DOM) | Supported |
Hot Swappable | Yes |
Compliance | IEEE 802.3aq (10GBASE-LRM) |
Transmit Power | -6.5 to +0.5 dBm |
Receiver Sensitivity | -8.4 dBm |
Extinction Ratio | 3.5 dB |
Overload | 0.5 dBm |
Storage Temperature | -40 to 85��C (-40 to 185��F) |
Humidity | 5% to 95% non-condensing |
Certifications | RoHS-6 compliant |
