Juniper QFX5130-32CD-AFO Specifications | |
| Brand | Juniper |
| Model | QFX5130-32CD-AFO |
| Port Configuration | 32 x 400G |
| Form Factor | 1U |
| Airflow Design | Port side intake/PSU side exhaust |
| Power Supply | Redundant, hot-swappable |
| Interface Types | QSFP-DD |
| Switching Capacity | 25.6 Tbps |
| Forwarding Capacity | 8 Bpps |
| Latency | Sub-microsecond |
| Management Ports | 1 x RJ-45 console, 1 x RJ-45 management, 1 x USB 2.0 |
| Memory | 16 GB DRAM |
| Flash Storage | 64 GB |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 5% to 90% non-condensing |
| Dimensions | 43.2 cm x 43.2 cm x 4.4 cm |
| MAC Address Table Size | 200,000 entries |
| VLAN IDs Supported | 4,096 |
| Network Operating System | Juniper Junos OS |
| Supported Protocols | OSPF, BGP, MPLS, PIM, IGMP |
