SFP-10G-ZR - Cisco SFP Module Overview
SFP-10G-ZR - Cisco SFP Module is a genuine modular capacity expansion product from Cisco, a global name in networking whose platforms are used by enterprises, service providers and data-center operators alike. Belonging to the Cisco family, the SFP-10G-ZR unit is built to the original factory specification, so it integrates with existing Cisco deployments predictably and behaves exactly as the platform documentation describes. In the network, it is installed into a compatible chassis slot, where it works alongside the supervisor and line cards to extend the platform’s capabilities.
This unit follows the original factory specification for the Cisco family, covering its intended role without compatibility surprises. Standard mounting, cabling and management practices apply, and it interoperates with surrounding hardware using the same procedures as other Cisco equipment already deployed in the network.
Typical deployments include short-reach data-center interconnects, campus backbone fiber links, and carrier access and metro networks. Organizations commonly source it for refresh programs, capacity expansion and spares management, keeping a tested unit on hand so outages stay short and replacements are predictable. The factory detail for this unit reads: “10GBASE-ZR SFP10G Module for SMF”. This makes it a practical choice when original-spec hardware is required at a predictable cost.
Every unit at LinkNewNet is inspected and tested before dispatch, and stock is graded, cleaned and verified for correct operation, including port status, console access and firmware state. Our warranty coverage and responsive technical support protect the purchase after it arrives, and our team can confirm revision levels and software compatibility before you order. For volume requirements we also offer configuration checks and staged delivery options.
Contact our sales team for current availability, lead time and shipping options for the SFP-10G-ZR. We respond quickly with stock status and a firm quote, so you can plan the refresh or expansion with confidence.
Key Specifications
Applications
Capacity Expansion
Add ports and performance to existing chassis.
Upgrade Path
Modernize aging platforms with compatible modules.
Flexible I/O
Mix copper, fiber and high-speed uplinks.
Buying a Pre-Owned SFP-10G-ZR
Verify the unit is tested, firmware confirmed, and condition documented. Every unit is fully tested and warranty covered. Contact our team for current stock and availability.
Cisco SFP-10G-ZR Specification | |
SFP+ port cabling specifications | |
Cable Type | SMF |
Core Size (Microns) | G.652 |
Wavelength (nm) | 1550 |
Cable Distance | 80km |
Optical transmit and receive specifications | |
Type | 10GBASE-ZR 1550nm SMF |
Transmit Power (dBm) | 4.0 (Max), 0 (Min) |
Receive Power (dBm) | -7 (Max), -24 (Min) |
Transmit and Receive Wavelength (nm) | 1530 to 1565 |
Other Specification | |
Bail Latch Color | Green |
Power Consumption (W) | 1.5 |
Operating Temperature Range | COM |
Dimensions | Dimensions (H x W x D): 8.5 x 13.4 x 56.5mm. Cisco SFP+ connectors typically weigh 75 grams or less. |
Operating Temperature Range | ● Commercial temperature range (COM): 0 to 70°C (32 to 158°F) ● Extended temperature range (EXT): -5 to 85°C (23 to 185°F) ● Industrial temperature range (IND): -40 to 85°C (-40 to 185°F) ● Storage temperature range: -40 to 85°C (-40 to 185°F) |
