T3048-LY2R - QuantaMesh 3000 Series Overview
T3048-LY2R - QuantaMesh 3000 Series is a genuine network infrastructure product from the vendor, a well-established networking hardware vendor. Belonging to the the vendor family, the T3048-LY2R unit is built to the original factory specification, so it integrates with existing the vendor deployments predictably and behaves exactly as the platform documentation describes. In the network, it is deployed as a standalone unit or as part of a larger managed network, following the standard operating procedures of the platform.
From a specification standpoint, it offers 48 ports for client, server or uplink connectivity; aggregate capacity of 1280 Gbps; packet forwarding up to 952 Mpps. These are the original factory figures for this model, giving administrators a clear picture of what the unit can deliver before it enters service. Standard mounting, cabling and management practices apply, so deployment follows the same procedures as other the vendor hardware already running in the environment.
Typical deployments include general network infrastructure support, general network infrastructure support, and general network infrastructure support. Organizations commonly source it for refresh programs, capacity expansion and spares management, keeping a tested unit on hand so outages stay short and replacements are predictable. The factory detail for this unit reads: “Low latency layer 2/3/4 Ethernet switch with 48 1/10GbE SFP+ and 4 40GbE QSFP+ ports”. This makes it a practical choice when original-spec hardware is required at a predictable cost.
Every unit at LinkNewNet is inspected and tested before dispatch, and stock is graded, cleaned and verified for correct operation, including port status, console access and firmware state. Our warranty coverage and responsive technical support protect the purchase after it arrives, and our team can confirm revision levels and software compatibility before you order. For volume requirements we also offer configuration checks and staged delivery options.
Contact our sales team for current availability, lead time and shipping options for the T3048-LY2R. We respond quickly with stock status and a firm quote, so you can plan the refresh or expansion with confidence.
Key Specifications
Applications
Enterprise Campus
High-density ports power users, phones and APs at the access layer.
Branch Office
Stackable units simplify branch deployment and management.
Wireless & IoT
PoE budget supports dense wireless and IoT endpoints.
Buying a Pre-Owned T3048-LY2R
Verify the unit is tested, firmware confirmed, and condition documented. Every unit is fully tested and warranty covered. Contact our team for current stock and availability.
| T3048-LY2R | |
| Product list | |
| Product code | T3048-LY2R |
| Product parameters | |
| Port configuration | 48 1/10GbE SFP+ and 4 40GbE QSFP+ ports |
| USB | USB 2.0 |
| Switching capacity | 1280Gbps |
| Maximum forwarding rate | 952Mpps |
| MAC | 128K |
| Console Port | 1 (RJ-45) |
| Management Port | Out-of-band management port (RJ-45, 10/100/1000Base-T) |
| CPU | NXP PPC P2020 |
| Redundant power supply | 1+1 |
| Hot-swappable fan tray | N+1 |
| Dimension (HxWxD) | 44x435x393mm |
| Weight | 7.83kg/17.31lbs (NET) |
| Operating temperature | 0~45°C |
| Operating humidity | 90% maximum relative humidity |
| Power requirement | 100~240VAC, 50/60Hz |
| Power consumption | 179 watts (L2 64B line rate; 10G-SR optics, 100% fan duty) |
| Safety | UL, cUL, CB, BSMI, CCC |
| EMC | CE, FCC, VCCI, KCC, BSMI, CCC |
| RoHS | Reduction of Hazardous Substances (RoHS) 6 |
T3048-LY2R - Product Notes
This listing is a specific SKU variant of the T3048-LY2R family. Review the specifications above and confirm compatibility with your existing infrastructure, including software version, mounting, and interface requirements, before ordering.
For volume requirements we offer configuration checks and staged delivery options. Our team can confirm revision levels, software compatibility, and lead time before you place an order.
Every unit at LinkNewNet is inspected and tested before dispatch, and stock is graded, cleaned and verified for correct operation.
