AIR-CAP3702E-H-K9 Cisco Aironet 3700 Series wireless Access Point

Model: AIR-CAP3702E-H-K9

Detail: Cisco Aironet 3700 Series Access Point - 802.11 a/g/n/ac - 2.4GHz / 5GHz - 4*4 MIMO - External antennas - Control base - Modular architecture

Condition: USED

List Price: $425 Price: $255

Price is not finalPlease contact if any inquiry.

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

AIR-CAP3702E-H-K9 Specification
Devide Type	Wireless Access point
Regulatory domain	H regulatory domain
Supported wireless LAN controllers	● Cisco 2500 Series Wireless Controllers, ● Cisco Wireless Controller Module for ISR G2 ● Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches ● Cisco 5500 Series Wireless Controllers ● Cisco Flex 7500 Series Wireless Controllers ● Cisco 8500 Series Wireless Controllers, Cisco Virtual Wireless Controller ● Cisco 5760 Wireless LAN Controller ● Cisco Catalyst 3850 Series Switches ● Cisco Catalyst 3650 Series Switches
Software	Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers: ● 7.6 or later for the Cisco Aironet 3700 Series Access Point ● 7.6 or later for support of the Wireless Security Module for the 3700 Series Access Point Cisco IOS XE Software Release: ● 3.3.1SE or later for the Cisco Aironet 3700 Series Access Point ● Wireless Security Module for the 3700 Series Access Point support – (T arget 1HCY15)
Data rates supported	● 802.11a: up to 54 Mbps ● 802.11g: up to 54 Mbps
Maximum number of nonoverlapping channels	5 GHz ● 802.11a: ◦ 20 MHz: 21 ● 802.11n: ◦ 20 MHz: 21 ◦ 40 MHz: 9 ● 802.11ac: ◦ 20 MHz: 21 ◦ 40 MHz: 9 ◦ 80 MHz: 4 ● 802.11n on 2.4 GHz: up to 216.7 Mbps ● 802.11ac on 5 GHz: up to 1.3Gbps 2.4 GHz ● 802.11b/g: ◦ 20 MHz: 3 ● 802.11n: ◦ 20 MHz: 3
Antenna	2.4 GHz, gain 4 dBi, internal omni, horizontal beamwidth 360° 5 GHz, gain 4 dBi, internal omni, horizontal beamwidth 360°
Interfaces	● 10/100/1000BASE-T autosensing (RJ-45) ● Management console port (RJ-45)
System memory	● 512 MB DRAM ● 64 MB flash
Module options	Cisco Aironet Wireless Security Module Cisco Universal Small Cell 5310
Power consumption	No external module installed, 4x4:3 on 2.4/5 GHz : 16.1 Watts with wireless Security module, 4x4:3 on 2.4/5 GHz +WSM: 19.6 Watts No external module installed, 3x3:3 on 2.4/5 GHz : 15.4 Watts with wireless Security module, 2x2:2 on 2.4/5 GHz +WSM: 15.4 Watts
IEEE standards	IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d
Security	● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA ● 802.1X ● IEEE 802.11ac Draft 5 ● Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)
Extensible Authentication Protocol (EAP) types	● EAP-Transport Layer Security (TLS) ● EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2) ● Protected EAP (PEAP) v0 or EAP-MSCHAPv2 ● EAP-Flexible Authentication via Secure Tunneling (FAST) ● PEAP v1 or EAP-Generic Token Card (GTC) ● EAP-Subscriber Identity Module (SIM)
Frequency band and 20-MHz operating channels	H (H regulatory domain): ● 2.412 to 2.472 GHz; 13 channels ● 5.150 to 5.350 GHz; 8 channels ● 5.745 to 5.825 GHz; 5 channels
Environmental	● Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C) ● Nonoperating (storage) altitude test: 25˚C, 15,000 ft. ● Operating temperature: 32° to 104°F (0° to 40°C) ● Operating humidity: 10% to 90% percent (noncondensing) ● Operating altitude test: 40˚C, 9843 ft.

Q&A

Are there any alternative products to the AIR-CAP3702E-H-K9?

Alternatives include the Cisco Aironet 3800 Series or the Cisco Catalyst 9100 Series, offering different performance features depending on network needs.

How does the modular architecture of this access point enhance flexibility?

The modular design allows for future upgrades and adding new modules, which extends the product life and adapts to evolving network requirements.

What accessories are available for the AIR-CAP3702E-H-K9?

Compatible accessories include a variety of external antennas, mounting kits, and power injectors to optimize installation and performance.

What steps should be taken if the AIR-CAP3702E-H-K9 experiences connectivity issues?

Check for firmware updates, verify external antenna connections, and ensure proper placement of the device. Consult Cisco's troubleshooting guide for in-depth support.

How cost-effective is the AIR-CAP3702E-H-K9?

The Cisco Aironet 3700 Series Access Point offers high performance with a modular design, making it cost-effective for scalability.

What are the key characteristics of the AIR-CAP3702E-H-K9?

This access point features 802.11 a/g/n/ac support, 2.4GHz and 5GHz bands, 4x4 MIMO, and external antennas.

What application scenarios is the AIR-CAP3702E-H-K9 suitable for?

Ideal for high-density environments like schools, hospitals, and large enterprise campuses requiring robust wireless access.

How do I install the AIR-CAP3702E-H-K9 Access Point?

Mount the access point, connect the Ethernet cable, and power it up via PoE. Configuration can be done through the controller.

Does the AIR-CAP3702E-H-K9 require firmware upgrades?

Regular firmware updates are recommended for optimal performance and security.

Are there alternative products to the AIR-CAP3702E-H-K9?

Alternatives include Cisco Aironet 3800 Series or Meraki MR42, offering similar features with enhanced functionalities.

What common troubleshooting steps should I take for the AIR-CAP3702E-H-K9?

Ensure power and Ethernet connectivity, check for firmware updates, and verify controller configurations.

What accessories are available for the AIR-CAP3702E-H-K9?

Accessories include external antennas, mounting brackets, and power injectors for flexible deployment options.

How does the AIR-CAP3702E-H-K9 compare to other similar products?

The AIR-CAP3702E-H-K9 provides superior performance in high-density environments compared to other access points like the AP 2600 Series.

Is the AIR-CAP3702E-H-K9 compatible with 802.11ac?

Yes, the AIR-CAP3702E-H-K9 fully supports the 802.11ac wireless standard for higher throughput and improved performance.

What are the standout features of the Cisco Aironet 3700 Series Access Point?

The Cisco Aironet 3700 Series Access Point features 802.11 a/g/n/ac support, dual 2.4GHz and 5GHz frequency bands, 4x4 MIMO, and modular architecture, making it highly versatile for various network environments.

How cost-effective is the AIR-CAP3702E-H-K9 for system integrators?

The AIR-CAP3702E-H-K9 offers a cost-effective solution with advanced features like 802.11ac support, 4x4 MIMO, and modular design, which help future-proof network infrastructure investments.

What installation considerations should be made for this access point?

Ensure to place the AIR-CAP3702E-H-K9 in optimal locations for signal strength, and integrate it with external antennas for better coverage. Follow Cisco's installation guidelines for best results.

Does the AIR-CAP3702E-H-K9 require regular firmware updates?

Yes, to maintain performance and security, it's recommended to regularly check and install firmware updates for the AIR-CAP3702E-H-K9.

What are the suitable application scenarios for this Cisco access point?

Ideal for enterprise environments, educational institutions, and large public venues due to its robust performance, 4x4 MIMO, and external antennas for extended range.

How does the 4x4 MIMO feature benefit network performance?

The 4x4 MIMO capability of the AIR-CAP3702E-H-K9 provides multiple data streams for increased throughput and improved signal reliability, crucial for high-density environments.

Are there any alternative products to the AIR-CAP3702E-H-K9?

Alternatives include the Cisco Aironet 3800 Series or the Cisco Catalyst 9100 Series, offering different performance features depending on network needs.

How does the modular architecture of this access point enhance flexibility?

The modular design allows for future upgrades and adding new modules, which extends the product life and adapts to evolving network requirements.

What accessories are available for the AIR-CAP3702E-H-K9?

Compatible accessories include a variety of external antennas, mounting kits, and power injectors to optimize installation and performance.

What steps should be taken if the AIR-CAP3702E-H-K9 experiences connectivity issues?

Check for firmware updates, verify external antenna connections, and ensure proper placement of the device. Consult Cisco's troubleshooting guide for in-depth support.
