Juniper EX-SFP-FE20KT15R13 Specifications | |
Brand | Juniper |
Product Name | Juniper EX-SFP-FE20KT15R13 |
Form Factor | SFP |
Type | 100Base-BX Fast Ethernet Optics |
Transmission Distance | Up to 20 km |
Transmitter Wavelength | 1550 nm |
Receiver Wavelength | 1310 nm |
Compatible Cable Type | Single-mode Fiber (SMF) |
DOM Support | Yes |
Connector Type | LC Duplex |
Max Data Rate | 100 Mbps |
Temperature Range | 0 to 70��C (32 to 158��F) |
Power Consumption | Less than 1W |
Compliance | MSA Compliant |
TX Output Power | -3 to -9 dBm |
RX Sensitivity | < -20 dBm |
Saturation Optical Power | > -3 dBm |
Extinction Ratio | 9 dB |
Certification | RoHS Compliant |
Application | Fast Ethernet, Metro access rings, Point-to-point networking |
Compatibility | Compatible with Juniper networks |
