S2700-26TP-SI-AC Specification | |
Product Description | Huawei Quidway S2700-26TP-SI-AC - switch - 24 ports - Managed - desktop |
Device Type | Switch - 24 ports - Managed - stackable |
Enclosure Type | Desktop |
Interfaces | Gigabit Ethernet |
Subtype | Gigabit Ethernet |
Ports | 24 x 10/100 + 2 x combo Gigabit SFP |
Performance | Forwarding performance : 6.6 Mpps |
Capacity | Virtual interfaces (VLANs) : 4000 |
MAC Address Table Size | 8K entries |
Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv6 routing |
Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI |
Features | VLAN support, IGMP snooping, IPv6 support, Access Control List (ACL) support, Quality of Service (QoS), Multicast Suppression |
Compliant Standards | IEEE 802.1Q, IEEE 802.1p |
Power | AC 120/230 V ( 50/60 Hz ) |
Dimensions (WxDxH) | 44.2 cm x 22 cm x 4.4 cm |
Weight | 2.4 kg |
Extended Specification |
|
General | |
Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
Capacity | Virtual interfaces (VLANs) : 4000 |
Compliant Standards | IEEE 802.1Q, IEEE 802.1p |
Device Type | Switch - 24 ports - Managed - stackable |
Enclosure Type | Desktop |
Features | VLAN support, IGMP snooping, IPv6 support, Access Control List (ACL) support, Quality of Service (QoS), Multicast Suppression |
Interfaces | Gigabit Ethernet |
MAC Address Table Size | 8K entries |
Performance | Forwarding performance : 6.6 Mpps |
Ports | 24 x 10/100 + 2 x combo Gigabit SFP |
Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI |
Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv6 routing |
Subtype | Gigabit Ethernet |
Dimensions (W x D x H) | 44.2 cm × 22 cm × 4.4 cm |
Weight | 2.4 kg |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 10 - 90% (non-condensing) |
Max Operating Temperature | 50 °C |
Max Storage Temperature | 55 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -5 °C |
Expansion / Connectivity | |
Interfaces | 2 x 1000Base-T - RJ-45 ¦ 24 x 100Base-TX - RJ-45 ¦ 1 x console - RJ-45 - management ¦ 2 x SFP (mini-GBIC) |
Power | |
Power Consumption Operational | 15.5 Watt |
Power Device | Internal power supply |
Voltage Required | AC 120/230 V ( 50/60 Hz ) |
