AIR-ANT25137NP-R|LinkNewNet

AIR-ANT25137NP-R Cisco Antennas - Dual Band

Model: AIR-ANT25137NP-R

Detail: Cisco AIR-ANT25137NP-R 2.4 GHz 13 dBi/5 GHz 7 dBi 802.11n Dual Band Patch Antenna

Condition: USED

List Price: $691 Price: $415

Price is not finalPlease contact if any inquiry.

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

AIR-ANT25137NP-R Specifications
Brand	Cisco
Model	AIR-ANT25137NP-R
Type	Dual Band Patch Antenna
Frequency Band	2.4 GHz / 5 GHz
Gain (2.4 GHz)	13 dBi
Gain (5 GHz)	7 dBi
Technology Standard	802.11n
Polarization	Linear, Vertical
Beamwidth (H-Plane)	30??
Beamwidth (E-Plane)	30??
Connector Type	RP-TNC
VSWR	2.0:1
Impedance	50 Ohms
Operating Temperature	-22??F to 158??F (-30??C to 70??C)
Dimensions	10.6 in x 3.9 in x 1.1 in
Wind Rating	100 mph (161 km/h)
Mounting	Wall/Mast
Radome Material	Polycarbonate
Color	Gray
Application	Indoor/Outdoor

Q&A

What accessories are available with the AIR-ANT25137NP-R?

Accessories include mounting brackets, extension cables, and lightning arrestors.

How does the AIR-ANT25137NP-R compare with similar antennas?

Compared to the AIR-ANT2566P4W-R, the AIR-ANT25137NP-R has a higher gain at 2.4 GHz but lower at 5 GHz.

What is the coverage range of the AIR-ANT25137NP-R?

Coverage varies by environment but typically covers several hundred meters outdoors.

Can the AIR-ANT25137NP-R antenna be used with any Cisco AP?

It is compatible with most Cisco access points supporting external antennas.

What is the gain of the AIR-ANT25137NP-R antenna?

The AIR-ANT25137NP-R antenna offers 13 dBi gain at 2.4 GHz and 7 dBi gain at 5 GHz.

Is the AIR-ANT25137NP-R suitable for both indoor and outdoor use?

Yes, the AIR-ANT25137NP-R can be used in both indoor and outdoor environments.

How does the AIR-ANT25137NP-R antenna enhance wireless performance?

The AIR-ANT25137NP-R improves wireless performance with its 13 dBi/7 dBi dual band capability.

What are common applications for the AIR-ANT25137NP-R antenna?

Common applications include wireless bridging and point-to-point connections.

How do I install the AIR-ANT25137NP-R antenna?

The AIR-ANT25137NP-R includes mounting hardware for easy installation on walls or poles.

Does the AIR-ANT25137NP-R require regular maintenance?

The AIR-ANT25137NP-R is low-maintenance but should be checked periodically for optimal performance.

Are there alternative antennas to the AIR-ANT25137NP-R?

Yes, alternative antennas include the Cisco AIR-ANT2524DG-R and AIR-ANT2547VG-N.

What are the primary features of the AIR-ANT25137NP-R antenna?

The AIR-ANT25137NP-R features dual-band support (2.4 GHz and 5 GHz) and high gain design.

Can the AIR-ANT25137NP-R be used with any 802.11n access point?

Yes, the AIR-ANT25137NP-R is compatible with any 802.11n access point.

How does the AIR-ANT25137NP-R compare to other Cisco antennas?

The AIR-ANT25137NP-R offers higher gain at 2.4 GHz compared to other Cisco dual-band patch antennas.

What are the key features of the AIR-ANT25137NP-R antenna?

The Cisco AIR-ANT25137NP-R has dual-band capabilities with 13 dBi gain at 2.4 GHz and 7 dBi gain at 5 GHz, supporting 802.11n Wi-Fi standard.

Is the AIR-ANT25137NP-R antenna suitable for outdoor use?

Yes, the Cisco AIR-ANT25137NP-R is designed for indoor and outdoor applications.

How do I install the AIR-ANT25137NP-R antenna?

Installation involves mounting the antenna on a pole or wall, connecting it to the access point, and aligning it for optimal coverage.

What application scenarios are ideal for the AIR-ANT25137NP-R?

The AIR-ANT25137NP-R is ideal for campuses, warehouses, and outdoor spaces requiring extended wireless coverage.

Does the AIR-ANT25137NP-R need regular firmware updates?

The antenna itself does not need updates, but ensure the connected Cisco devices have the latest firmware.

Are there alternative products to the AIR-ANT25137NP-R?

Alternatives include the Cisco AIR-ANT2566P4W-R and the AIR-ANT2544V4M-R for different coverage and gain specifications.

What accessories are available with the AIR-ANT25137NP-R?

Accessories include mounting brackets, extension cables, and lightning arrestors.

How does the AIR-ANT25137NP-R compare with similar antennas?

Compared to the AIR-ANT2566P4W-R, the AIR-ANT25137NP-R has a higher gain at 2.4 GHz but lower at 5 GHz.

What is the coverage range of the AIR-ANT25137NP-R?

Coverage varies by environment but typically covers several hundred meters outdoors.

Can the AIR-ANT25137NP-R antenna be used with any Cisco AP?

It is compatible with most Cisco access points supporting external antennas.
