AIR-SAP2602E-A-K9|LinkNewNet

AIR-SAP2602E-A-K9 Cisco Aironet 2600 Series Access Points

Model: AIR-SAP2602E-A-K9

Detail: Cisco Aironet 2600 Series Access point; 802.11n Auto ; 3x4:3SS; Mod;EXt Ant; A Reg Domain - External antennas - standalone model

Condition: USED

List Price: $682 Price: $409

Price is not finalPlease contact if any inquiry.

Shipping:

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

AIR-SAP2602E-A-K9 Specifications
Software	Cisco Unified Wireless Network Software Release 7.2.110 or later.
Supported Wireless LAN Controllers	● Cisco 2500 Series, Cisco Wireless LAN Controller Module (WLCM) on Cisco Services Ready Engine (SRE) for Integrated Services Router Generation 2 (ISR G2), Cisco Wireless Services Module 2 (WiSM2), Cisco 5500 Series, Cisco Flex 7500 Series
802.11n Version 2.0 (and Related) Capabilities	● 3x4 multiple-input multiple-output (MIMO) with three spatial streams ● Maximal ratio combining (MRC) ● 802.11n and 802.11a/g beamforming ● 20- and 40-MHz channels ● PHY data rates up to 450 Mbps (40-MHz with 5 GHz) ● Packet aggregation: Aggregated MAC Protocol Data Unit (A-MPDU) (Tx/Rx), Aggregated MAC Protocol Service Unit (A-MSDU) (Tx/Rx) ● 802.11 dynamic frequency selection (DFS) ● Cyclic shift diversity (CSD) support
Data Rates Supported	802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
Data Rates Supported	802.11bg: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
Maximum Number of Nonoverlapping Channels	2.4 GHz ● 802.11b/g: ◦ 20 MHz: 3 ● 802.11n: ◦ 20 MHz: 3	5 GHz ● 802.11a: ◦ 20 MHz: 21 ● 802.11n: ◦ 20 MHz: 21 ◦ 40 MHz: 9
Note: This varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.
Maximum Transmit Power	2.4 GHz ● 802.11b ◦ 22 dBm: 3 Antennas ● 802.11g ◦ 22 dBm: 3 Antennas ● 802.11n (HT20) ◦ 22 dBm: 3 Antennas	5 GHz ● 802.11a ◦ 23 dBm: 4 Antennas ● 802.11n (HT20) ◦ 23 dBm: 4 Antennas ● 802.11n (HT40) ◦ 23 dBm: 4 Antennas
Note: The maximum power setting will vary by channel and according to individual country regulations. Refer to the product documentation for specific details.
Available Transmit Power Settings	2.4 GHz ● 22 dBm (160 mW) ● 19 dBm (80 mW) ● 16 dBm (40 mW) ● 13 dBm (20 mW) ● 10 dBm (10 mW) ● 7 dBm (5 mW) ● 4 dBm (2.5 mW)	5 GHz ● 23 dBm (200 mW) ● 20 dBm (100 mW) ● 17 dBm (50 mW) ● 14 dBm (25 mW) ● 11 dBm (12.5 mW) ● 8 dBm (6.25 mW) ● 5 dBm (3.13 mW)
Note: The maximum power setting will vary by channel and according to individual country regulations. Refer to the product documentation for specific details.
Integrated Antenna	● 2.4 GHz, Gain 4 dBi, internal omnidirectional, horizontal beamwidth 360° ● 5 GHz, Gain 4 dBi, internal omnidirectional, horizontal beamwidth 360°
External Antenna (Sold Separately)	● Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz) ● Cisco offers the industry's broadest selection of 802.11n antennas delivering optimal coverage for a variety of deployment scenarios
Interfaces	● 10/100/1000BASE-T autosensing (RJ-45) ● Management console port (RJ-45)
Indicators	● Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
Dimensions (W x L x H)	● Access point (without mounting bracket): 8.69x8.69x2.11in. (22.1x22.1x5.4)
Weight	● 2.3 lbs (1.04 kg) (2.7 lbs for external)
Environmental	Cisco Aironet 2600i ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test 25˚C, 15,000 ft. ● Operating temperature: 32 to 104°F (0 to 40°C) ● Operating humidity: 10 to 90% percent (noncondensing) ● Operating Altitude Test: 40˚C, 9843 ft. Cisco Aironet 2600e ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test: 25˚C, 15,000 ft. ● Operating temperature: -4 to 131°F (-20 to 55°C) ● Operating humidity: 10 to 90 % (noncondensing) ● Operating Altitude Test: 40˚C, 9843 ft.
System Memory	● 256 MB DRAM ● 32 MB flash
Input Power Requirements	● AP2600: 44 to 57 VDC ● Power Supply and Power Injector: 100 to 240 VAC; 50 to 60 Hz
Powering Options	● 802.3af Ethernet Switch ● Cisco AP2600 Power Injectors (AIR-PWRINJ4=) ● Cisco AP2600 Local Power Supply (AIR-PWR-B=)
Power Draw	● AP2600: 12.95W Note: When deployed using Power over Ethernet (PoE), the power drawn from the power sourcing equipment will be higher by some amount depending on the length of the interconnecting cable. This additional power may be as high as 2.45W, bringing the total system power draw (access point + cabling) to 15.4W.
Warranty	Limited Lifetime Hardware Warranty

Q&A

What common troubleshooting steps are recommended for the Cisco Aironet 2600 Series Access Point?

Check power supply, ensure firmware is up-to-date, and verify configuration settings for common issues with the AIR-SAP2602E-A-K9.

What accessories are available for the Cisco Aironet 2600 Series Access Point?

Available accessories include external antennas and mounting kits, which enhance the flexibility and performance of the AIR-SAP2602E-A-K9.

How does the Cisco Aironet 2600 Series Access Point compare with its competitors?

The AIR-SAP2602E-A-K9 stands out due to its robust performance, 3x4:3SS MIMO, and external antennas compared to other models in its price range.

How can I maximize the performance of the Cisco Aironet 2600 Series Access Point?

Position the AIR-SAP2602E-A-K9 strategically, use external antennas as needed, and keep firmware up-to-date for optimal performance.

How cost-effective is the Cisco Aironet 2600 Series Access Point?

The Cisco Aironet 2600 Series offers a robust performance with its 802.11n technology, providing a good balance of cost and high throughput for enterprise environments.

What are the main characteristics of the Aironet 2600 Series Access Point?

The Aironet 2600 Series features 802.11n Auto, 3x4:3SS configurations, modular design, and external antennas, optimizing wireless connectivity.

What are the ideal application scenarios for the Aironet 2600 Series?

This access point is ideal for high-density environments such as offices, schools, and large retail spaces where robust wireless performance is critical.

How do I install the Cisco Aironet 2600 Series Access Point?

Installation involves mounting the access point on a wall or ceiling, connecting the external antennas, and configuring it via the web interface.

Does the Aironet 2600 need regular firmware upgrades?

Yes, regularly updating the firmware ensures optimal performance, security patches, and access to new features for the Aironet 2600 Series.

Are there alternative products to the Cisco Aironet 2600 Series Access Point?

Alternatives include the Cisco Aironet 1600 Series for smaller deployments and the 3600 Series for more advanced wireless needs.

What accessories are available for the Aironet 2600 Series?

Available accessories include external antennas, mounting brackets, and power injectors to enhance the deployment and performance of the access point.

How does the Aironet 2600 Series compare to similar access points?

The Aironet 2600 Series offers superior performance with its 3x4:3SS MIMO configuration compared to similar products within the same price range.

What should I do if I encounter connectivity issues with the Aironet 2600 Series Access Point?

Troubleshoot by checking the external antenna connections, ensuring the firmware is up to date, and examining network configurations.

Is the Aironet 2600 suitable for use as a standalone model?

Yes, the Aironet 2600 can operate effectively as a standalone model, providing reliable wireless coverage without the need for a wireless controller.
