Cisco Router ASR 1000 Series ASR1001-2XOC3POS Overview
Cisco ASR 1000 chassis ASR1001-2XOC3POS, featuring crypto, 4 built-in GE, and OC3 IDC.
4Memory
ASR1001-2XOC3POSModel
VerifiedBrand
Key Specifications
Expansion Slots1 (total) / 0 (free) x expansion slot
Power DeviceInternal power supply
Ram4 GB (installed) / 8 GB (max)
Line RateOC-3
Device TypeRouter
Connectivity TechnologyWired
Applications
Enterprise WAN
Branch and campus routing with advanced services.
Service Provider
Edge routing for ISP and MPLS deployments.
Data Center
Interconnect core and aggregation layers reliably.
Buying a Pre-Owned ASR1001-2XOC3POS
Verify the unit is tested, firmware confirmed, and condition documented. Every unit is fully tested and warranty covered. Contact our team for current stock and availability.
ASR1001-2XOC3POS Specification | |
| General | |
| Device Type | Router |
| Enclosure Type | Desktop - modular - 1U |
| Connectivity Technology | Wired |
| Performance | Bandwidth: 2.5 Gbps ¦ VPN throughput (IPSec): 1.8 Gbps |
| Features | Firewall protection, NAT support, VPN support, load balancing, Intrusion Prevention System (IPS), Access Control List (ACL) support, Quality of Service (QoS) |
| RAM | 4 GB (installed) / 8 GB (max) |
| Line Properties | |
| Line Rate | OC-3 |
| Interfaces | Management: 1 x 10Base-T/100Base-TX - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ Management: 1 x auxiliary - RJ-45 ¦ USB: 1 x ¦ WAN: 2 x OC-3 ¦ 4 x SFP (mini-GBIC) |
| Expansion Slots | 1 (total) / 0 (free) x expansion slot |
| Installed Modules Qty (Max) | 1 (installed) / 1 (max) |
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Installed Qty | 2 (installed) / 2 (max) |
| Width | 17.3 in |
| Height | 1.7 in |
