AIR-CAP3602I-KK910 Cisco 3600i Series Access Points Eco Packs

Model: AIR-CAP3602I-KK910

Detail: Cisco AIR-CAP3602I-KK910 802.11n CAP 10APs w/CleanAir; 4x4:3SS; Mod; Int; K RegDomain

Condition: USED

List Price: $8741 Price: $5245

Price is not finalPlease contact if any inquiry.

Shipping: DHL, FedEx, UPS, etc

Availability: In Stock

*These items are in Good condition. Items may have scratches, if you need mint condition let us know and we will see if we have a unit that meets your needs.

*These items have been fully tested by our professional tech team. Test notes available upon request.

Tags：

Delivery

After receiving the order, we will carry out detailed testing and maintenance of the equipment before shipmentSothe order equipment usually will be shipped within 2 or 3 workdays.

Warranty

Equipment is sold with a3-month free warranty policy. If you need to extend the warranty period, please contact our sales team

Product Condition

All of devicesare in good operating condition, having been fully tested by professional technical engineers. Testing instructions also could be provided according to customer’s requirements. There may be scratches on the appearance of used products. please confirm that with our sales team before purchasing.

Payment

Import duties and taxes are not included in the product price or shipping costs. Please contact with the customs office in your country for checking with the additional charges before the itemsarriving at your customs location.

Product Details

AIR-CAP3602I-KK910 Specification
Product Description	Cisco Catalyst 3600 Series Access Points with integrated antennas
Devide Type	Wireless Access point
Regulatory domain	A regulatory domain
Supported wireless LAN controllers	● Cisco 2500 Series Wireless Controllers ● Cisco Wireless Controller Module for ISR G2 ● Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches ● Cisco 5500 Series Wireless Controllers
Software	Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers: ● 7.2 or later for the Cisco Aironet 3600 Series Access Point ● 7.4 or later for support of the Wireless Security Module for the 3600 Series Access Point ● 7.5 or later for support of the 802.11ac Wave 1 Module for the 3600 Series Access Point
Data rates supported	● 802.11a: up to 54 Mbps ● 802.11g: up to 54 Mbps
Antenna (integrated)	● 2.4 GHz, gain 4 dBi, internal omni, horizontal beamwidth 360°
Interfaces	● 10/100/1000BASE-T autosensing (RJ-45)
System memory	● 256 MB DRAM
Module options	● Cisco Aironet Wireless Security Module ● Cisco Aironet IEEE 802.1ac Wave 1 Module
Power consumption (purchase separately)	● No external module installed, 4x4:3 on 2.4/5 GHz : 16.1 Watts
	● No external module installed, 3x3:3 on 2.4/5 GHz : 15.4 Watts
IEEE standards	● IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d
Security	● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA ● 802.1X
Extensible Authentication Protocol (EAP) types	● EAP-Transport Layer Security (TLS) ● EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2) ● Protected EAP (PEAP) v0 or EAP-MSCHAPv2
Integrated Antenna	● 2.4 GHz, Gain 2 dBi, internal omni, horizontal beamwidth 360° ● 5 GHz, Gain 4 dBi, internal omni, horizontal beamwidth 360°
External Antenna (Sold Separately)	● Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
Indicators	● Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
Dimensions (W x L x H)	● Access point (without mounting bracket): 8.7 x 8.7 x 2.11 in. (22.1 x 22.1 x 5.4 cm)
Weight	● 2.5 lbs (1.13 kg)
Environmental	Cisco Aironet 3600i ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test -25˚C, 15,000 ft. ● Operating temperature: 32 to 104°F (0 to 40°C) ● Operating humidity: 10 to 90% percent (noncondensing) ● Operating Altitude Test -40˚C, 9843 ft. Cisco Aironet 3600e ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test - 25˚C, 15,000 ft. ● Operating temperature: -4 to 131°F (-20 to 55°C) ● Operating humidity: 10 to 90 percent (noncondensing) ● Operating Altitude Test -40˚C, 9843 ft.

Q&A

What are common troubleshooting steps for the AIR-CAP3602I-KK910?

Common steps include restarting the access point, checking for firmware updates, ensuring correct power supply, and verifying network configurations.

What accessories are available for the AIR-CAP3602I-KK910?

Accessories include mounting kits, external antennas (if using with an external module), and power injectors for flexible power options.

How does the AIR-CAP3602I-KK910 compare to similar products?

Compared to other models, the AIR-CAP3602I-KK910 stands out with its CleanAir technology and 4x4:3 spatial stream capability, providing superior performance in high-density environments.

Is the AIR-CAP3602I-KK910 compatible with existing network infrastructure?

Yes, the Cisco AIR-CAP3602I-KK910 is designed to integrate seamlessly with existing Cisco network infrastructure, ensuring easy scalability and management.

What are the primary features of the Cisco AIR-CAP3602I-KK910?

The Cisco AIR-CAP3602I-KK910 features 802.11n with CleanAir technology, 4x4 MIMO, 3 spatial streams, internal antennas, and operates in the K regulatory domain.

Is the Cisco AIR-CAP3602I-KK910 cost-effective for enterprise use?

Yes, it offers advanced features like CleanAir and MIMO technology at a competitive price point, making it cost-effective for enterprises.

What application scenarios are ideal for the Cisco AIR-CAP3602I-KK910?

This product is ideal for high-density environments such as office buildings, campuses, and public venues where reliable wireless connectivity is crucial.

How do I install the Cisco AIR-CAP3602I-KK910 access point?

Installation involves mounting the unit on a ceiling or wall, connecting to a network switch, and configuring via the Cisco Controller. Detailed guides are available online.

Does the Cisco AIR-CAP3602I-KK910 require regular upgrades?

Firmware updates may be necessary to ensure performance and security, which can be managed through the Cisco wireless controller.

Are there any alternative products to the Cisco AIR-CAP3602I-KK910?

Alternatives include the Cisco AIR-AP2802I which offers 802.11ac support and higher throughput for modern network environments.

What accessories are available for the Cisco AIR-CAP3602I-KK910?

Accessories include mounting kits, power injectors, and external antennas to suit different installation requirements.

How does the Cisco AIR-CAP3602I-KK910 compare to the AIR-CAP3702I?

The AIR-CAP3702I offers improved 802.11ac technology, potentially higher throughput, but at a higher price point compared to the 3602I.

What common troubleshooting steps should I follow for the Cisco AIR-CAP3602I-KK910?

Common steps include checking connections, ensuring proper firmware updates, and consulting the Cisco Controller for real-time diagnostic data.

What are the benefits of the CleanAir technology in Cisco AIR-CAP3602I-KK910?

CleanAir technology automatically detects and mitigates RF interference, ensuring consistent and reliable wireless performance.

How cost-effective is the AIR-CAP3602I-KK910?

The Cisco AIR-CAP3602I-KK910 offers a competitive price point with advanced features like CleanAir technology and 4x4:3 spatial streams, providing excellent value for high-performance wireless networks.

What are the key features of the AIR-CAP3602I-KK910?

The key features include 802.11n compatibility, CleanAir technology, 4x4:3 spatial streams, modular architecture, internal antennas, and compliance with the K regulatory domain.

In which scenarios can the AIR-CAP3602I-KK910 be deployed?

This Cisco 3600 access point is ideal for high-density environments like offices, educational institutions, and commercial spaces where reliable and high-speed wireless coverage is needed.

How do I install the AIR-CAP3602I-KK910?

The Cisco AIR-CAP3602I-KK910 can be mounted on ceilings or walls. Use the provided mounting bracket and follow the installation guide for secure and optimal placement.

Does the AIR-CAP3602I-KK910 require updates?

Yes, periodically check for firmware updates on Cisco's website to ensure the access point has the latest security patches and performance enhancements.

Are there alternative products to the AIR-CAP3602I-KK910?

Alternatives include other models in the Cisco 3600 series or the Cisco 3700 series, offering varying features and performance levels.
