AIR-CAP3602I-QK910 Cisco 3600i Series Access Points Eco Packs Overview
AIR-CAP3602I-QK910 Cisco 3600i Series Access Points Eco Packs is a genuine wireless coverage and secure client access product from Cisco, a leading enterprise networking vendor whose Catalyst, Nexus and ISR families power campus, data-center and branch networks worldwide. Belonging to the Cisco 3600i Series family, the AIR-CAP3602I-QK910 unit is built to the original factory specification, so it integrates with existing Cisco deployments predictably and behaves exactly as the platform documentation describes. In the network, it is deployed as a standalone unit or as part of a larger managed network, following the standard operating procedures of the platform.
This unit follows the original factory specification for the Cisco 3600i Series family, covering its intended role without compatibility surprises. Standard mounting, cabling and management practices apply, and it interoperates with surrounding hardware using the same procedures as other Cisco equipment already deployed in the network.
Typical deployments include high-density wireless for offices and halls, branch and remote-site Wi-Fi coverage, and guest networks and IoT onboarding. Organizations commonly source it for refresh programs, capacity expansion and spares management, keeping a tested unit on hand so outages stay short and replacements are predictable. The factory detail for this unit reads: “Cisco AIR-CAP3602I-QK910 802.11n CAP 10APs w/CleanAir; 4x4:3SS; Mod; Int; Q RegDomain”. This makes it a practical choice when original-spec hardware is required at a predictable cost.
Every unit at LinkNewNet is inspected and tested before dispatch, and stock is graded, cleaned and verified for correct operation, including port status, console access and firmware state. Our warranty coverage and responsive technical support protect the purchase after it arrives, and our team can confirm revision levels and software compatibility before you order. For volume requirements we also offer configuration checks and staged delivery options.
Contact our sales team for current availability, lead time and shipping options for the AIR-CAP3602I-QK910. We respond quickly with stock status and a firm quote, so you can plan the refresh or expansion with confidence.
Key Specifications
Applications
Campus Coverage
High-density wireless for offices and halls.
Branch Wi-Fi
Cost-effective coverage for remote sites.
Guest & IoT
Isolated guest networks and IoT onboarding.
Buying a Pre-Owned AIR-CAP3602I-QK910
Verify the unit is tested, firmware confirmed, and condition documented. Every unit is fully tested and warranty covered. Contact our team for current stock and availability.
AIR-CAP3602I-QK910 Specification | |
Product Description | Cisco Catalyst 3600 Series Access Points with integrated antennas |
Devide Type | Wireless Access point |
Regulatory domain | A regulatory domain |
Supported wireless LAN controllers | ● Cisco 2500 Series Wireless Controllers |
Software | Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers: |
Data rates supported | ● 802.11a: up to 54 Mbps |
Antenna (integrated) | ● 2.4 GHz, gain 4 dBi, internal omni, horizontal beamwidth 360° |
Interfaces | ● 10/100/1000BASE-T autosensing (RJ-45) |
System memory | ● 256 MB DRAM |
Module options | ● Cisco Aironet Wireless Security Module |
Power consumption (purchase separately) | ● No external module installed, 4x4:3 on 2.4/5 GHz : 16.1 Watts |
| ● No external module installed, 3x3:3 on 2.4/5 GHz : 15.4 Watts |
IEEE standards | ● IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d |
Security | ● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA |
Extensible Authentication Protocol (EAP) types | ● EAP-Transport Layer Security (TLS) |
Integrated Antenna | ● 2.4 GHz, Gain 2 dBi, internal omni, horizontal beamwidth 360° ● 5 GHz, Gain 4 dBi, internal omni, horizontal beamwidth 360° |
External Antenna (Sold Separately) | ● Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz) |
Indicators | ● Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
Dimensions | ● Access point (without mounting bracket): 8.7 x 8.7 x 2.11 in. (22.1 x 22.1 x 5.4 cm) |
Weight | ● 2.5 lbs (1.13 kg) |
Environmental | Cisco Aironet 3600i ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test -25˚C, 15,000 ft. ● Operating temperature: 32 to 104°F (0 to 40°C) ● Operating humidity: 10 to 90% percent (noncondensing) ● Operating Altitude Test -40˚C, 9843 ft. Cisco Aironet 3600e ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C) ● Nonoperating (storage) Altitude Test - 25˚C, 15,000 ft. ● Operating temperature: -4 to 131°F (-20 to 55°C) ● Operating humidity: 10 to 90 percent (noncondensing) ● Operating Altitude Test -40˚C, 9843 ft. |
