S5720-28X-PWH-LI-AC Specifications | |
Brand | Huawei |
Product Name | S5720-28X-PWH-LI-AC |
Product Series | S5700 Series Switches |
Device Type | Switch - 24 ports - L3 - Managed |
Enclosure Type | Rack-mountable 1U |
Ports | 24 x 10/100/1000 + 4 x 10 Gig SFP+ |
Performance | Switching capacity: 128 Gbps |
Throughput | Up to 95.2 Mpps |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 9216 bytes |
Routing Protocol | Static IP routing, RIP-1, RIP-2, BGP-4, IS-IS, OSPF, PIM-SM, PIM-DM |
RAM | 512 MB |
Flash Memory | 512 MB |
Power Over Ethernet (PoE) | Supported |
Power Supply | Included |
Voltage Required | AC 120/230 V (50/60 Hz) |
Features | Layer 3 switching, layer 2 switching, DHCP support, VPN support, ARP support, VLAN support, IGMP snooping, port mirroring, MAC address filtering |
Compliance Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1x, IEEE 802.1ab (LLDP) |
Dimensions (WxDxH) | 440 mm x 420 mm x 44 mm (Approx.) |
Operating System | VRP (Versatile Routing Platform) |
