S5720-52X-PWR-LI-ACF Specifications | |
| Product Name | S5720-52X-PWR-LI-ACF |
| Brand | Huawei |
| Series | S5700 |
| Device Type | Switch - 48 ports - Managed |
| Enclosure Type | Rack-mountable 1U |
| Ports | 48 x 10/100/1000 + 4 x 10 Gig SFP+ |
| Performance | 130.9 Mpps |
| Switching Capacity | 176 Gbps |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9216 bytes |
| Power Over Ethernet (PoE) | PoE+ |
| Power Supply | AC 110/220V (50/60Hz) |
| Network Protocols | Supports IPv4/IPv6, SNMP, RMON, HTTP, HTTPS, Ethernet OAM, and more |
| Quality of Service (QoS) | Advanced QoS features |
| Security Features | ACLs, ARP inspection, 802.1X, DHCP Snooping, IPSG, and more |
| Management | Web-based Management, CLI, SNMP, RMON, sFlow |
| Stackable | Yes |
| Dimensions (WxDxH) | 442 mm x 420 mm x 43.6 mm |
| Mounting | Rack Mountable |
| Fan | Three fans, providing redundant fan protection |
