S5720SV2-28P-LI-AC Specifications | |
| Product Name | S5720SV2-28P-LI-AC |
| Brand | Huawei |
| Series | S5700 |
| Device Type | Switch - 28 ports - Managed |
| Enclosure Type | Rack-mountable 1U |
| Ports | 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 370 W |
| Performance | Switching capacity: 128 Gbps |
| Throughput | Up to 95.2 Mpps |
| RAM | 512 MB |
| Flash Memory | 256 MB |
| Management | SNMP 1, RMON 2, SNMP 3, SNMP 2c, HTTP, CLI |
| Authentication Methods | RADIUS, TACACS+ |
| Compliant Standards | NEBS level 3, FCC Part 15 A, CISPR 22 Class A |
| Power | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | Maximum 445 W |
| Dimensions (W x D x H) | 442 mm x 220 mm x 43.6 mm |
