| S5720-52X-SI-48S Specifications | |
| Brand | Huawei |
| Product Name | S5720-52X-SI-48S |
| Product Series | S5700 |
| Device Type | Switch - 48 ports - Managed |
| Enclosure Type | Rack-mountable 1U |
| Ports | 48 �� 10/100/1000 + 4 �� 10 Gig SFP+ |
| Performance | Switching capacity: 336 Gbps |
| Forwarding Rate | 132 Mpps |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9216 bytes |
| VLAN Support | Yes |
| Power Over Ethernet (PoE) | Not supported |
| Power Supply | Included |
| Power Redundancy | Optional |
| Operating Humidity | 5% to 95% (non-condensing) |
| Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1q, IEEE 802.3ae |
| Management | Web-based management, SNMP, RMON |
| Quality of Service (QoS) | Advanced QoS features |
| Security Features | ACLs, Secure Shell (SSH), Secure Sockets Layer (SSL), IEEE 802.1X |
